Home » PID-S Series P1.53 Indoor LED Module - Ultra-Fine Pitch LED Display Module | 320×160mm | 22,050 Pixels RGB Tile | 1.53mm Pixel Pitch | High-Resolution Panel | 1pcs / 40pcs
PrimeLEDModules

PID-S Series P1.53 Indoor LED Module - Ultra-Fine Pitch LED Display Module | 320×160mm | 22,050 Pixels RGB Tile | 1.53mm Pixel Pitch | High-Resolution Panel | 1pcs / 40pcs

In stock
SKU: MZ01-PID-S-P1.53-01
$45.85
Pixel Pitch
Package Qty

P1.53 Indoor LED Module

The P1.53 indoor LED module is an ultra-fine-pitch RGB display panel designed for high-precision indoor LED video walls. With a 1.53 mm pixel pitch, 208 × 104 resolution, and a standard 320 × 160 mm size, it provides clear and stable visuals for corporate displays, command rooms, retail signage, conference screens, and immersive digital installations.

Using copper-wired SMD1212 LEDs, 12–14 bit color processing, a 3840 Hz refresh rate, and a 1/52 scan drive, the module delivers smooth gradients, accurate color reproduction, and reliable long-term performance. Brightness reaches ≥600 nits, and its low color decay combined with a 160° viewing angle helps maintain consistent image quality in indoor environments.

The module supports magnetic front service or rear-screw maintenance, offering flexible installation and seamless panel alignment. It is compatible with creative LED formats such as curved, cylindrical, and custom-dimension displays, making it suitable for professional indoor LED projects requiring precision and stability.

Packing Details

Version Package Included
1-Pack Sample Kit 1 × P1.53 Indoor LED Module
1 × 5V Power Cable 1-to-2 Split
1 × Data Cable
40-Pack Standard Carton 40 × P1.53 Indoor LED Module
20 × 5V Power Cable 1-to-2 Split
40 × Data Cable

Purchase Recommendations and Importation Information

  • Same Batch Purchase: To ensure optimal performance and consistency, we recommend purchasing LED modules from the same production batch. This will help avoid discrepancies in brightness, color display, and configuration between different batches.

  • Spare Parts: Ordering extra modules as spare parts is advised for future maintenance, ensuring consistent display quality in the long term.

  • Full Project Purchases: To maintain uniformity in your LED screen project, we recommend purchasing enough modules and necessary spare parts at once.

Shipping Information

  • Lead Time: In-stock products ship within 1–3 business days

  • Packaging: Safe packaging with foam padding to ensure safe transport.

  • Shipping Origin: All products ship directly from our warehouse.

  • Standard Shipping: 9–18 days | Express Shipping: 5–9 days

  • Shipping Costs: Calculated based on cart weight, dimensions, and destination

Technical Specifications

Specification Details
P/N P1.53
Item Indoor LED Module
Pixel Pitch 1.53 mm
LED Configuration Copper Wired SMD1212
Module Resolution 208 × 104 dots
Pixel Density 432,640 dots/m²
Module Size (W × H) 320 × 160 mm
Surface Process SMD
Module Mask No need
Hub Connection Port HUB75
Module Weight 0.46 kg
Color Processing (Bit) 12–14 bit
Gray Level 16–65,536 adjustable levels
Refresh Rate 3840 Hz
Driving Mode (Scan) 1/52
Standard Brightness ≥600 nits (SMD)
Viewing Angle (H/V) 160° / 160°
Input Voltage AC110/220V ±10%
Input Power Frequency 50/60 Hz
Max Power Consumption 20 W per module
Operating Temperature -10°C ~ 60°C
Operating Humidity 10% ~ 90% RH
Storage Humidity 10% ~ 85% RH, no condensation
Lifetime ≥100,000 hours
Usage Environment Indoor fixed installation
Maintenance Method Magnetic front or screw rear

Applications

  • Indoor Environments: Retail shops, conference rooms, exhibitions, broadcast studios, and control centers.

  • Creative Displays: Video walls, artistic installations, and custom-shaped LED designs.

  • Brand Showcases: High-impact visual displays for product launches and retail branding.

  • Professional Settings: Ideal for monitoring rooms, studios, and commercial indoor signage.
