NovaStar MCTRL600 Professional Sending Controller
The NovaStar MCTRL600 LED Sender Box is a high-performance external sending controller designed for professional LED display projects. Equipped with HDMI and DVI video inputs and a 4-port Gigabit Ethernet output, it supports multiple LED screen configurations with stable video transmission and precise color control. Offering up to 2.3 million pixel loading capacity, it is ideal for both fixed and rental LED display setups.
With advanced NovaStar features such as cascading support, light-sensor integration, and wide-range AC power compatibility, the MCTRL600 ensures long-term reliability for indoor and outdoor LED displays. Its compact engineering and efficient heat dissipation make it suitable for commercial displays, stage events, and large LED installations.
Packing Details
| Version | Package Included |
|---|---|
| MCTRL600 | 1 × MCTRL600 Sender Box 1 × Power Cable 1 × DVI Cable 1 × USB Cable 1 × User Manual |
Shipping Information
-
Lead Time: In-stock products ship within 1–3 business days.
-
Packaging: Safe packaging with foam padding to ensure safe transport.
-
Shipping Origin: All products ship directly from our warehouse.
-
Standard Shipping: 9–18 days | Express Shipping: 5–9 days.
-
Shipping Costs: Calculated based on cart weight, dimensions, and destination.
Key Specifications
-
DVI Video Input + Audio Input
-
Dual Ethernet Outputs
-
Supports up to 1920×1200@60Hz
-
USB Control with Cascading
-
Wide Voltage: AC100–240V
-
Works in –20°C to +60°C
Installation Tips
-
Power Off First: Always switch off the LED display system before installing or removing the receiving card to prevent damage.
-
Use Shielded Network Cables: Ensure stable, interference-free signal transmission for consistent display performance.
-
Maintain Adequate Ventilation: Keep proper airflow inside the LED cabinet to guarantee long-term reliable operation.
-
Anti-Static Precautions: Avoid static discharge; always use anti-static protection when handling the receiving card.
Technical Specifications
| Specification | Details |
|---|---|
| Video Inputs | HDMI, DVI — supports mainstream LED display video sources |
| Audio Support | HDMI embedded audio and external 3.5mm input |
| Max Input Resolution | 1920×1200 / 2048×1152 / 2560×960 (custom resolutions supported) |
| Loading Capacity | Up to 2.3 million pixels for large LED displays |
| Control & Configuration | USB control, multi-controller cascading, quick setup |
| Compatible Video Formats | RGB, YCrCb 4:2:2, YCrCb 4:4:4 |
| Output Ports | 4 × Gigabit Ethernet ports for stable LED data transmission |
| Input Bit Depth | Compatible with 8-bit / 10-bit / 12-bit video sources |
| Light Sensor Port | Supports automatic brightness adjustment |
| Power Requirements | AC 100–240V, 50/60Hz |
| Certifications | CE, RoHS, FCC, EAC, IC |
Applications
-
Fixed Outdoor LED Billboards: Permanent advertising screens, building façades, and public information displays.
-
Rental Stage LED Screens: Concerts, touring events, exhibitions, and large-scale rental setups.
-
Indoor/Outdoor Commercial Displays: Retail signage, shopping malls, transportation hubs, and outdoor advertising panels.
-
Conference, Exhibition, and Event Displays: Meeting rooms, exhibition halls, corporate events, and professional stage backgrounds.
