The Outdoor Flexible LED Display Modules – POF Series provide professional flexible display solutions for engineered curved, cylindrical, concave, convex, and custom-shaped outdoor LED installations. Covering pixel pitches from P2.5 to P10, the current collection uses a standardized 320×160mm module format for outdoor advertising, architectural displays, media façades, cylindrical screens, and other creative outdoor LED projects.
The collection includes POF-S all-in-one silicone flexible modules and POF-SR rear-cover flexible modules. POF-S models combine a silicone flexible back structure, magnetic alignment, and M3 mechanical fixing, while POF-SR models add a protective rear-cover structure with front installation and front-service maintenance. Protection ratings, LED packages, brightness, fixing methods, bending limits, service configurations, and minimum order quantities vary by model and should be confirmed on the corresponding product page.
Complete your outdoor LED display system with our recommended essentials:
Need an indoor flexible display solution? Discover our PIF Series Indoor Flexible LED Modules ›
Handling time begins after the product configuration, order quantity, payment, and technical requirements have been confirmed. It does not include shipping time.
Shipping fees are not included in the product prices and will be calculated separately based on the actual freight cost, destination, package size, total weight, and selected delivery method.
This collection supports sample evaluation where available, bulk purchasing, channel stocking, system integration, engineering procurement, and project-based delivery.
For large-quantity orders, please contact us to confirm the product configuration, order quantity, production schedule, freight arrangement, and delivery plan.
A matching module size and pixel pitch do not guarantee direct compatibility with an existing LED display. Before ordering replacement modules or planning a mixed installation, confirm the module structure, mounting and safety-fixing method, bending direction and limit, LED package, signal interface and pinout, scan rate, driver IC, power connection and polarity, receiving-card configuration, firmware, calibration data, protection rating, and production batch. Modules used within the same screen should be sourced from the same confirmed product configuration and production batch whenever possible to improve mechanical fit, brightness, color, and calibration consistency.
Module-level protection ratings do not automatically define the environmental protection of the completed LED display. The supporting structure, module seams, rear enclosure, connectors, cable entries, drainage, ventilation, grounding, lightning protection, wind-load resistance, and installation workmanship must also be designed for the project environment.
If you are replacing existing modules, expanding an installed screen, or selecting modules for a new curved outdoor structure, please CONTACT US before ordering. Please provide the existing product label, front and rear photographs, PCB markings, connector details, control-system information, required curvature or cylinder diameter, screen dimensions, and installation drawings for compatibility review.
10 Products
The POF Series Outdoor Flexible LED Modules include 10 current products across two structural platforms: POF-S all-in-one silicone flexible modules and POF-SR rear-cover flexible modules. The collection covers pixel pitches from P2.5 to P10 in a standardized 320×160mm module format for engineered curved, cylindrical, concave, convex, and other custom-shaped outdoor LED installations.
Brightness, LED package, bending limit, fixing method, protection rating, service configuration, and minimum order quantity vary by model. Final selection should therefore be based on the corresponding product specification and the complete display structure rather than module size or pixel pitch alone.
| Sub-Series | Structure | Module Size | Available Pixel Pitches | Brightness | Protection Configuration | Installation & Service |
|---|---|---|---|---|---|---|
| POF-S | All-in-One Silicone Flexible Structure | 320×160mm | P2.5, P3.076, P4, P5, P6.67, P8, P10 | Approximately ≥3600–4200 nits, depending on model | IP65-rated module protection according to the stated product specification | Magnetic alignment with M3 mechanical fixing; service method depends on the engineered support structure |
| POF-SR | Flexible PCB, Silicone Bottom Case & Protective Rear Cover | 320×160mm | P2.5, P3.076, P4 | 5000 nits | IP65-rated front protection and IP54-rated rear-cover protection | Magnetic positioning with front installation and front-service maintenance on compatible structures |
Choose POF-S when the project requires an integrated silicone flexible back structure, a wider pitch range from P2.5 to P10, magnetic alignment, and M3 mechanical fixing. This platform supports both detailed curved displays and larger-format outdoor installations.
Choose POF-SR when the project prioritizes a protective rear-cover structure, front installation, front-service maintenance, 5000-nit brightness, and separately defined IP65 front and IP54 rear-cover protection in P2.5, P3.076, or P4.
Supports engineered concave, convex, cylindrical, wave-shaped, and other curved structures within the documented bending direction and limit of the selected model.
Model-dependent brightness from approximately 3600 to 5000 nits supports outdoor content visibility under different ambient-light and viewing conditions.
POF-S and POF-SR use different protection structures. Always verify whether the stated rating applies to the complete module or to a particular side of the module.
Magnets assist positioning and module alignment. They should not automatically be treated as the only structural restraint for elevated or exposed outdoor installations.
POF-S models provide M3 screw fixing. Additional model-appropriate safety restraints should be considered according to the supporting structure and installation environment.
P2.5–P4 models support closer viewing and finer image detail, while P5–P10 models provide practical coverage for larger screens and longer viewing distances.
POF modules use silicone-based flexible structures and protected power and signal interfaces to improve resistance to dust, moisture, and outdoor environmental exposure. Protection construction differs between the POF-S and POF-SR platforms, so the rating shown on the corresponding product page should be used for project evaluation.
Protected power and data interfaces can improve module-level environmental resistance. Controllers, receiving cards, power supplies, distribution equipment, and exposed connections must still be installed in appropriately rated enclosures or protected locations according to the complete display design.
POF modules must be installed on a compatible, accurately fabricated support structure. The frame should provide the required curvature, flatness, load capacity, wind-load resistance, drainage, ventilation, grounding, cable routing, and service access.
Magnetic components assist positioning and alignment during installation. POF-S models also use M3 mechanical fixing, while POF-SR installations should include a model-appropriate mechanical restraint or safety system where required by the project design. The temperature rating of a magnet applies only to that component and does not replace the module’s operating-temperature specification.
The POF Series currently covers P2.5, P3.076, P4, P5, P6.67, P8, and P10. A smaller pixel pitch provides higher pixel density and finer detail at the same physical screen size, while a larger pixel pitch can provide more economical coverage for larger displays viewed from a greater distance.
The final pixel pitch should be selected according to viewing distance, content detail, required native resolution, screen dimensions, curvature, brightness, structural design, control-system requirements, and project budget.
Find quick answers about outdoor flexible modules, including applications, installation, compatibility, and product performance.
