NovaStar TB40 Multimedia Player – Dual-Mode LED Controller with HDMI Preview, 1.3 Million Pixel Capacity for Pro Displays

In stock
SKU: PL-PKZQ01-NS-TB40
$239.85
Package Qty

NovaStar TB40 Dual-Mode LED Controller with Preview

The NovaStar TB40 is a high-performance dual-mode LED controller designed for professional indoor and outdoor LED displays. Supporting up to 1.3 million pixels with HDMI preview, dual HDMI splicing, and multi-window playback, it ensures stable and flexible operation for both fixed installations and rental setups.

Equipped with HDMI, DVI, and Ethernet input/output, NTP/GPS sync, optional 4G connectivity, and dual-mode operation, the TB40 delivers reliable performance. Its compact metal case and efficient heat dissipation make it ideal for long-term, high-demand LED applications.

Packing Details

Version Package Included
TB40 1 × TB40 Multimedia Player
1 × Antistatic Bag
1 × User Manual

Shipping Information

  • Lead Time: In-stock products ship within 1–3 business days.

  • Packaging: Safe packaging with foam padding to ensure safe transport.

  • Shipping Origin: All products ship directly from our warehouse.

  • Standard Shipping: 9–18 days | Express Shipping: 5–9 days.

  • Shipping Costs: Calculated based on cart weight, dimensions, and destination.

Key Specifications

  • HDMI & DVI dual input
  • 2 × Ethernet output ports (Main + Backup)
  • Max load: 1.3 million pixels
  • Supports 4096 × 4096 resolution
  • Dual-mode operation: synchronous & asynchronous playback
  • Optional 4G connectivity
  • USB, Network, WiFi control
  • Compact metal case with efficient heat dissipation

Installation Tips

  • Power Off First: Always switch off the LED display system before installing or removing the sender box to prevent damage.

  • Use Shielded Network Cables: Ensure stable, interference-free signal transmission for consistent display performance.

  • Maintain Adequate Ventilation: Keep proper airflow inside the LED cabinet to guarantee long-term reliable operation.

  • Anti-Static Precautions: Avoid static discharge; always use anti-static protection when handling the sender box.

Technical Specifications

Specification Details
CPU 4 Core A55 / 1.8GHz
Storage 1GB + 32GB
Decode Ability 4K 60fps
Operating System Android 11
Max Capacity 1.3 million pixels
Max Width / Max Height 4096 × 4096
Number of Video Windows 1×4K / 2×1080P / 4×720P / 4×480P / 6×360P
LED Output Port 2 Main
Sync Mode NTP, GPS
Dual Mode Switch √
HDMI Splicing Playback √ 1080p, up to level 8
Audio Output √
Sensor Two aviation plugs
USB Local Playback √ USB3.0
LAN 1000 Mbps
WiFi 2.4G Switchable AP & STA
4G Support (Option)
5G Support (Option)
Viplex Handy (Cloud / PC / Mobile) √
Novastar SDK Agreement √
Appearance Material Metal Case
Power Port AC 100–240V
Certification CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE

Applications

  • Fixed Outdoor LED Billboards: Permanent advertising screens, building façades, and public information displays.

  • Rental Stage LED Screens: Concerts, touring events, exhibitions, and large-scale rental setups.

  • Indoor/Outdoor Commercial Displays: Retail signage, shopping malls, transportation hubs, and outdoor advertising panels.

  • Conference, Exhibition, and Event Displays: Meeting rooms, exhibition halls, corporate events, and professional stage backgrounds.
