NovaStar TB60 Multimedia Player – High-Performance Dual-Mode LED Controller with HDMI Input, 2.3 Million Pixel Loading

In stock
SKU: PL-PKZQ01-NS-TB60
$459.85
Package Qty

NovaStar TB60 High-Performance Dual-Mode LED Controller

The NovaStar TB60 Multimedia Player is a high-performance dual-mode LED controller designed for modern commercial signage and professional LED installations. Supporting up to 2.3 million pixels with a maximum resolution of 4096 × 4096, it delivers smooth asynchronous playback and real-time synchronous display via HDMI input.

With support for LAN, Wi-Fi, and optional 4G/5G modules, the TB60 enables flexible deployment without a dedicated PC. HDMI splicing playback, dual-mode switching, and accurate NTP/GPS time synchronization ensure stable, reliable 24/7 operation. Ideal for retail screens, outdoor lamp-post displays, shopfront signage, mirror displays, and small-to-medium LED video walls.

Packing Details

Version Package Included
TB60 1 × NovaStar TB60 Multimedia Player
1 × Power Cable
1 × Antistatic Bag
1 × User Manual

Shipping Information

  • Lead Time: In-stock products ship within 1–3 business days.

  • Packaging: Safe packaging with foam padding to ensure safe transport.

  • Shipping Origin: All products ship directly from our warehouse.

  • Standard Shipping: 9–18 days | Express Shipping: 5–9 days.

  • Shipping Costs: Calculated based on cart weight, dimensions, and destination.

Key Specifications

  • HDMI input with 1080p splicing playback

  • 4 × RJ45 LED outputs (Main) for flexible screen layouts

  • Max load: 2.3 million pixels (4096 × 4096 max resolution)

  • Dual-mode operation: synchronous & asynchronous

  • LAN + 2.4G Wi-Fi (AP/STA) + optional 4G/5G

  • USB local playback for PC-free deployment

  • Compact metal chassis for continuous 24/7 operation

Installation Tips

  • Power Off First: Always switch off the LED display system before installing or removing the sender box to prevent damage.

  • Use Shielded Network Cables: Ensure stable, interference-free signal transmission for consistent display performance.

  • Maintain Adequate Ventilation: Keep proper airflow inside the LED cabinet to guarantee long-term reliable operation.

  • Anti-Static Precautions: Avoid static discharge; always use anti-static protection when handling the sender box.

Technical Specifications

Specification TB60
CPU 4-Core A55 Processor / 1.8GHz
Storage 1GB RAM + 32GB Flash
Decode Ability 4K @ 60fps
Operating System Android 11
Max Capacity 2.3 million pixels
Max Resolution 4096 × 4096
Number of Video Windows 1×4K / 2×1080P / 4×720P / 4×480P / 6×360P
LED Output Ports (RJ45) 4 × Main
Sync Mode NTP, GPS
Dual Mode Switch Supported
HDMI Splicing Playback 1080p, up to level 8
Audio Output Supported
Sensor Access Two aviation connectors
Remote Power Control Requires Multifunction Card
USB Local Playback USB 3.0
LAN 1000 Mbps
Wi-Fi 2.4G Switchable AP & STA
4G Supported (Optional)
5G Supported (Optional)
Viplex Handy Cloud / PC / Mobile Supported
NovaStar SDK Supported
Material Metal Case
Power Port AC 100–240V
Certifications CE EMC, LVD, ROHS, FCC, FCC ID, IC, RED, UKCA, UL, RCM, PSE, FAC, PSB, KC, MIC, CB, NBTC

Applications

  • Fixed Outdoor LED Billboards: Permanent advertising screens, building façades, and public information displays.

  • Rental Stage LED Screens: Concerts, touring events, exhibitions, and large-scale rental setups.

  • Indoor/Outdoor Commercial Displays: Retail signage, shopping malls, transportation hubs, and outdoor advertising panels.

  • Conference, Exhibition, and Event Displays: Meeting rooms, exhibition halls, corporate events, and professional stage backgrounds.
