Datasheet of Outdoor Flexible LED Panels

Key Engineering Advantages

• IP65 Waterproof Construction – Fully sealed against rain splash, dust, and moisture for outdoor use.

• UV & Weather Resistance – Designed to withstand sunlight exposure and harsh environmental conditions.

• High Brightness (4500–5000 cd/m²) – Supports clear visibility in bright daylight for outdoor viewing.

• Flexible & Bendable Structure – Enables curved, cylindrical, wave-shaped, and irregular outdoor LED displays.

• Durable Silicone Encapsulation – Helps prevent aging issues such as bubbles or deformation over time.

• Multiple Pixel Pitch Options – Supports different resolutions for different viewing distances and project goals.

• Installer-Friendly Interfaces – Waterproof connectors and modular assembly simplify on-site installation.

1. IP65 Waterproof Rated for Outdoor Use

A silicone-based flexible LED module with both the front LED surface and backside fully protected by black silicone gel. This sealed structure supports reliable outdoor operation where rain splash, dust, and humidity are expected.

2. New-Generation Silicone Encapsulation for Protected Power & Data Interfaces

This updated design uses a silicone cover that shells both the power and data interfaces, improving overall sealing. For outdoor LED display projects, the module level can meet IP65 requirements; for complete system reliability, place controller equipment in a dry area or protected enclosure and use an appropriate waterproof power supply.

3. Thin, Flexible & Curvable for Irregular Outdoor LED Display Structures

The flexible display tiles can be bent into a controlled curve (approximately 120–150° in convex or concave), enabling curved outdoor LED screens, cylindrical LED displays, arches, and other custom-shaped installations.

4. Fast Installation & Stable Attachment

Magnetic mounting supports quick placement on-site. Combined with screw ports on the board, the module can be fixed to a variety of surfaces with stable attachment—useful for curved metalwork, custom frames, and engineered structural supports.

5. Pixel Pitch Options for Outdoor Viewing Distance

Available pitch options include 2.5 mm, 3.2 mm, 4 mm, 5 mm, and 8 mm to support different viewing distances and project objectives. Choose a finer pitch for closer viewing and a larger pitch for longer viewing distances and cost-efficient coverage.

NOTE: P2 is not available.

6. Diverse Outdoor Applications for Project Deployments

The following guidelines are recommended for safe handling, stable installation, and long-term reliability of outdoor flexible LED modules. For engineering deployments, always follow appropriate ESD practices and avoid installation methods that compromise flatness or structural integrity.

• ESD protection during assembly: Operators should wear anti-static gloves and follow standard ESD handling procedures.

• Do not splash water onto the module: Do not use wet rags or moisture-containing objects for cleaning. For dust removal, use an anti-static soft-bristled brush.

• Avoid excessive force on wiring: Do not tear or pull cables violently. When unplugging/plugging wires, pull gently to prevent damage to copper pillars and the PCB.

• Use structurally reliable frames: Galvanized square pipes are not recommended because flatness cannot be guaranteed. Use engineered metalwork such as sprayed iron cabinets/frames where flatness is controlled.

• For curved structures: Sprayed sheet-metal iron cabinets or curved frames are recommended for arc-shaped and cylindrical builds for easier installation and better flatness.

• Respect bending limits: The bending angle range is approximately 158°–162°. Do not bend the module violently or repeatedly, and avoid forcing the module beyond design limits.

Products on this page are supplied by an outdoor flexible LED module manufacturing source. For project inquiries, engineering questions, and outdoor installation guidance, support is typically available within one working day. https://www.led.app  or  https://www.360digitalsignage.com )

What Is an Outdoor Flexible LED Module?

An outdoor flexible LED module is a full-color LED display module designed for outdoor use with a bendable structure. It combines flexible shaping capabilities with waterproof sealing and high brightness, enabling project teams to build curved outdoor LED screens and creative displays. Typical pitch options range from P2.5 to P8, supporting both close-to-medium viewing and longer viewing distances depending on the project requirements.

What Defines a High-Quality Outdoor Flexible LED Module?

• Waterproof integrity for outdoor deployments: For outdoor flexible LED display modules, waterproof construction is a top priority. Outdoor installations face rain, humidity, and dust; reliable sealing reduces project risk and supports long-term operation.

• Stable flexibility and controlled bending: The module should bend smoothly within the defined bending angle range without damaging internal structures. Consistent curvature helps maintain visual uniformity and supports engineered cabinet or frame designs.

• High brightness and outdoor readability: Outdoor flexible LED panels should provide sufficient brightness for daytime visibility, helping content remain clear under direct sunlight and bright ambient conditions.

• Connector reliability and project-friendly assembly: Waterproof connectors and protected power/data interfaces reduce installation friction and improve field reliability. For outdoor projects, system components such as controllers and power supplies should also be protected using appropriate enclosures and waterproof-rated equipment.
